GAIA

ADDRESS: 46164 Junmin-dong, Yuseong-gu, Daejon, 305-811 Korea
PRIMARY CONTACT: Paul Choi
PRIMARY CONTACT INFO: paul@gaia21.co.kr
Distributor(s)
PROCESS DESCRIPTION

The GAIA dehydration system dries inputs to reduce their size in both volume and weight, which takes about eight to ten hours to complete. This process works by heating up the chamber to 300˚F+, shredding food waste by a built-in rotating double helix blade, and churning the food waste as air is circulated throughout the container; consider it an accelerated composting process. At the end of the cycle, it has reduced the food waste in both volume and weight by 85%+ and generates two viable by-products for reuse / recycling, if the client so elects. One is a highly concentrated organic (HCO) that can be reused / recycled as: (i) soil-like amendment, (ii) compost accelerant, animal feed, or (iv) a fuel pellet. The second is the sterile, filtered water that can be reused / recycled for: (i) landscaping, (ii) gardening, (iii) washing out trash bins, or (iv) discharged into the sewer.

GAIA also has the capability to custom design, manufacture, and install plant-sized facilities capable of processing 5, 10, 20, 50 or 100+ tons of food waste or bio-solids per day which are appropriate for municipalities, major food manufacturers, farmers, waste water treatment facilities. Larger units generally take 9 to 12 months to design, manufacture and install at a location. Call for more details.

Units

GAIA GC-20 Electric

  • PROCESSING CAPACITY RANGE
    0 - 250 lbs/day
  • WEIGHT LIMIT
    20 lbs x 2 cycles per day (40 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $10,000- $25,000
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    2'4"L x 2'4"D x 3'H
  • ENERGY USE
    25 kWh/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GC-30 Electric

  • PROCESSING CAPACITY RANGE
    0 - 250 lbs/day
  • WEIGHT LIMIT
    30 lbs x 2 cycles per day (60 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $10,000- $25,000
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    2'6"L x 3'6"D x 3'8"H
  • ENERGY USE
    35 kWh/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GC-50 Electric

  • PROCESSING CAPACITY RANGE
    0 - 250 lbs/day
  • WEIGHT LIMIT
    50 lbs x 2 cycles per day (100 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $25,000 - $50,000
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    2'7"L x 3'6"D x 3'10"H
  • ENERGY USE
    50 kWh/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GC-100 Electric

  • PROCESSING CAPACITY RANGE
    0 - 250 lbs/day
  • WEIGHT LIMIT
    110 lbs x 2 cycles per day (220 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $25,000 - $50,000
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    3'1"L x 4'9"D x 4'2"H
  • ENERGY USE
    80 kWh/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GC-150 Electric

  • PROCESSING CAPACITY RANGE
    250 - 750 lbs/day
  • WEIGHT LIMIT
    165 lbs x 2 cycles per day (330 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $25,000 - $50,000
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    3'5"L x 5'3"D x 4'11"H
  • ENERGY USE
    120 kWh/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GC-200 Electric

  • PROCESSING CAPACITY RANGE
    250 - 750 lbs/day
  • WEIGHT LIMIT
    220 lbs x 2 cycles per day (440 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $50,000 - $100,000
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    4'1"L x 5'7"D x 5'H
  • ENERGY USE
    160 kWh/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GC-300 Electric

  • PROCESSING CAPACITY RANGE
    250 - 750 lbs/day
  • WEIGHT LIMIT
    330 lbs x 2 cycles per day (660 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $50,000 - $100,000
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    4'3"L x 6'3"D x 5'9"H
  • ENERGY USE
    240 kWh/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GC-400 Electric

  • PROCESSING CAPACITY RANGE
    750 - 1,500 lbs/day
  • WEIGHT LIMIT
    440 lbs x 2 cycles per day (880 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $100,000 +
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    4'11"L x 7'11"D x 6'1"H
  • ENERGY USE
    320 kWh/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GC-600 Electric

  • PROCESSING CAPACITY RANGE
    750 - 1,500 lbs/day
  • WEIGHT LIMIT
    660 lbs x 2 cycles per day (1320 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $100,000 +
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    5'7"L x 8'6"D x 6'1"H
  • ENERGY USE
    450 kWh/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GC-1000 Electric

  • PROCESSING CAPACITY RANGE
    1,500 - 2,500 lbs/day
  • WEIGHT LIMIT
    1,100 lbs x 2 cycles per day (2200 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $100,000 +
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    5'11"L x 10'2"D x 6'7"H
  • ENERGY USE
    750 kWh/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GC-1200 Electric

  • PROCESSING CAPACITY RANGE
    1,500 - 2,500 lbs/day
  • WEIGHT LIMIT
    1320 lbs x 2 cycles per day (2640 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $100,000 +
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    6'1"L x 10'10"D x 6'8"H
  • ENERGY USE
    900 kWh/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GC-2000 Electric

  • PROCESSING CAPACITY RANGE
    2,500+ lbs/day
  • WEIGHT LIMIT
    2,200 lbs x 2 cycles per day (4400 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $100,000 +
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    7'3"L x 13'10"D x 8'3"H
  • ENERGY USE
    1,400 kWh/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GG-150H Gas

  • PROCESSING CAPACITY RANGE
    250 - 750 lbs/day
  • WEIGHT LIMIT
    165 lbs x 2 cycles per day (330 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $25,000 - $50,000
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    3'9"L x 5'5"D x 5'1"H
  • ENERGY USE
    19 & 15 Nm3/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GG-200H Gas

  • PROCESSING CAPACITY RANGE
    250 - 750 lbs/day
  • WEIGHT LIMIT
    220 lbs x 2 cycles per day (440 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $50,000 - $100,000
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    3'11"L x 5'9"D x 5'7"H
  • ENERGY USE
    20 & 20 Nm3/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GG-300H Gas

  • PROCESSING CAPACITY RANGE
    250 - 750 lbs/day
  • WEIGHT LIMIT
    330 lbs x 2 cycles per day (660 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $50,000 - $100,000
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    4'3"L x 6'1"D x 6'1"H
  • ENERGY USE
    20 & 30 Nm3/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GG-400H Gas

  • PROCESSING CAPACITY RANGE
    750 - 1,500 lbs/day
  • WEIGHT LIMIT
    440 lbs x 2 cycles per day (880 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $100,000 +
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    4'11"L x 8'2"D x 6'11"H
  • ENERGY USE
    28 & 38 Nm3/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GG-600H Gas

  • PROCESSING CAPACITY RANGE
    750 - 1,500 lbs/day
  • WEIGHT LIMIT
    660 lbs x 2 cycles per day (1,320 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $100,000 +
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    5'7"L x 8'7"D x 6'9"H
  • ENERGY USE
    48 & 56 Nm3/day (based on 2 cycles)
  • WATER USE
    N/A

GAIA GG-1200H Gas

  • PROCESSING CAPACITY RANGE
    2,500+ lbs/day
  • WEIGHT LIMIT
    1,320 lbs x 2 cycles per day (2,640 lbs total)
  • PROCESSING TIME
    10 hours
  • PRICE/PRICE RANGE
    $100,000 +
  • VOLUME/WEIGHT REDUCTION
    85-93%
  • PHYSICAL DIMENSION
    6'1"L x 11'10"D x 8'H
  • ENERGY USE
    65 & 110 Nm3/day (based on 2 cycles)
  • WATER USE
    N/A
PRODUCT WARRANTY
1 year
ADDITIONAL NOTES

Service Plan Offered: Yes
Option to Lease: Yes
Accepts FOG: No
Accepts Paper/Packaging: 10-15% max of compostable packaging
Prohibited Items: Large bones, silverware, cloth napkins, plastic bags, clam / oyster shells, cans, glass, avocado pits, grease, oil, etc.
